Type-A & Type-C USB Ports with 15A TR Receptacles DWUR-15D-1A1C-CC3.6

Short Description:

The DWUR-15D-1A1C-CC3.6 USB outlet is the /Tamper-Resistant Receptacle offers two USB charging ports and duplex Tamper-Resistant Receptacles. This DWUR-15 is able to charge any current electronic devices simultaneously, including smart phones, tablets, e-readers, cameras and MP3 players. What’s more, it has the capability to charge new device required higher current rating in the future. All you will need is a USB cable to connect to one of the two USB ports.

Send email to us

Product Detail

Product Tags

Product Description

Type-A & Type-C USB Ports with 15A TR Receptacles

--Type-A & Type-C
The USB-A and USB-C ports feature a total output of 5V DC, 3.6 A. in addition to two 15A plug outlets.

-- IntelliChip Technology
Identify and optimize the charging current of the devices.

--Easy Installation
The DWUR-15-1A1C-CC3.6 can fit in any standard in-wall outlet box and is also compatible with standard decorator wall plates.

--Wide Range of Applications

product-description2

Features

- Smart chip recognizes and optimizes the charging requirements of both of Apple and Android devices
- USB charger conforms to UL Energy Efficiency Certification requirement - Level VI
- 2 USB charging ports with a total output of 3.6 A
- Tamper Resistant (TR) Receptacles increase safety
- Charge electronic devices directly without an adapter
- Compliance with the NEC Section 406.11 code requirements
- Wall plate included (8831)
- Fits into a standard wall box

Technical Details

Part Number	DWUR-15-1A1C-CC3.6
Receptacle Rating	15 Amp, 125VAC
USB Rating	Two USB ports with total 3.6 Amp, 5VDC
Wire Terminals	#14-#12 AWG
Operating Temperature	-4 to 140°F (-20 to 60°C)
USB Compatibility.	USB 1.1/2.0/3.0 devices, including Apple products

Product Dimensions	4.06x1.71x1.73 inches
Color	white
Style	Wall Charger
Material	Plastic
Usage	‎Indoor Use Only
Batteries Included?	No
Batteries Required?	No
