ln Wall PIR Motion Sensor Light Switch WOS

Short Description:

Passive Infrared Wall Switch Occupancy Sensor, Single Pole, Relay Control

The WOS is an occupancy sensor with the addition of an always-on switch. This sensor switch automatically turns on the lights when you enter a room and automatically turns off the lights when motion is no longer detected. Enjoy savings on your energy bill, and add convenience to your home with this automatic lighting control.

Send email to us

Product Detail

Product Tags

Feature

-- 3 Operation Modes: On, Off, Auto
A slider switch on the face of the unit allows you to easily switch between Auto, On, and Off modes. Behind the cover plate, settings for the time delay, range, and light level are easily accessible and adjustable. Simply use a flathead screwdriver to turn each knob to the setting you desire!

-- Innovative PIR Technology
The WOS uses passive infrared (PIR) technology to detect occupancy by sensing the difference between heat emitted from the human body in motion and background space. Enjoy energy saving benefits by ensuring lights are always accurately turned off.

-- Sensor Override Feature
Use the WOS as an occupancy motion detector sensor, or set it to Off or On mode to override the sensor function. A neutral wire is required for installation. For single-pole applications only.

--Typical Applications

■ Bedrooms ■ Bathrooms ■ Laundry Rooms
■ Closets ■ Garages ■ Kitchens ■ Home Offices

Technical Details

Part Number	WOS
Operation Mode	Auto
Current Rating	4 Amp
Operating Voltage	120 Volts
Fluorescent	500VA
Incandescent	500 W
Motor	1/8HP
Circuit Type	Single Pole
Switch Type	Push Button Switch
Neutral Wire Required	Required
Usage	Indoor Use Only, In-Wall Use Only
Operating Temperature	32°F to 131°F(0°C to 55°C)
Time Delay	15 Sec to 30 Min
Light Level	30 Lux--Daylight
Batteries Included?	No
Batteries Required?	No
